Part #: 57009

2 HP Irrigation Pump Start Relay for Sprinkler Controllers

  • Automatically synchronizes an irrigation pump with your sprinkler controller for hands-free watering
  • Controls 120 VAC pumps up to 1 HP and 240 VAC pumps up to 2 HP for versatile pump compatibility
  • Durable water-resistant ABS enclosure withstands outdoor conditions for long-lasting performance
  • 24 VAC coil connects directly to your sprinkler controller's pump or master valve terminal
  • Compatible with Orbit, Hydro-Rain, B-hyve, and Husqvarna Automatic Irrigation Controllers
  • Works with a variety of water sources including wells, ponds, and bore holes
  • UL and CUL approved for safe, code-compliant installation
  • Includes mounting template, mounting hardware, wire nuts, and instruction sheet for easy setup

Take full control of your pump-fed irrigation system with the Orbit® 1-2 HP Pump Start Relay, engineered to automatically synchronize your irrigation pump with your sprinkler controller for reliable, hands-free watering. Whether your water source is a well, pond, or bore hole, this relay bridges your controller and pump so both operate in perfect coordination every time a watering cycle begins.

The relay supports 120 VAC pumps up to 1 HP and 240 VAC pumps up to 2 HP, with a 25A contact rating at 240V, making it suitable for a wide range of residential and light commercial pump installations. A 24 VAC coil connects the relay to the pump or master valve terminal on your sprinkler controller using standard AWG 16-24 sprinkler wire. The water-resistant ABS enclosure is built for outdoor durability and features conduit knockout plugs for clean, code-compliant wiring runs.

Installation is straightforward — mount the relay box at least 5 feet from your controller using the included mounting template and No. 8 hardware, connect your AC power wires (AWG 12 recommended), and wire the 24V leads to your controller's pump terminal. The relay is compatible with Orbit, Hydro-Rain, B-hyve, and Husqvarna Automatic Irrigation Controllers. UL and CUL approved for safe installation. For outdoor irrigation use with cold water only.

Upgrade your irrigation system with a relay built for dependability — add the Orbit® Pump Start Relay to your setup today.

  • In stock, ready to ship
  • Inventory on the way
$54.99
/
Shipping calculated at checkout.

Description

The pump start relay is engineered to synchronize an irrigation pump with an irrigation/sprinkler controller. It is effective for a variety of water sources, including wells, ponds, and bore holes. 24 VAC leads connect the controller to the relay. It is capable of actuating 120 VAC pumps up to 1HP and 230 VAC pumps up to 2HP. The enclosure is constructed from durable water-resistant plastic. The pump start relay is compatible with irrigation controllers from Orbit, Hydro-Rain, and other major brands. For outdoor irrigation use with cold water only.
